Touch Screen Display
Display Type: TFT Active matrix color LCD
Size: 5.7 inch (145 mm) diagonal Aspect Ratio: 4:3 VGA Resolution: 640 x 480 pixels Brightness: 350 nits (cd/m&³2;) Contrast: 800:1
Color Depth: 18-bit, 262k colors
Illumination: Edgelit LED
Viewing Angle: ±80° horizontal, ±70° vertical
Touch Screen: Projected Capacitive
Buttons, Switches, & Indicators
Sleep: (1) Top-mounted pushbutton (left); programmable, normally initiates “Sleep” mode when docked, turns power on/off when undocked; also resets the unit if held for 5 seconds
Brightness: (1) Top-mounted pushbutton (right); programmable, normally sets display brightness level
Hard Keys: (8) Optional pushbuttons, programmable, engravable backlit text[3]
Up/Down: (2) Optional backlit translucent “up” and “down” pushbuttons, programmable, engravable backlit text on bezel[3]
Navigation Pad: (5) Optional backlit translucent pushbuttons for 4-way directional navigation and “select”, programmable
Battery Switch: (1) Rear panel recessed slide switch, shuts off battery for long-term storage
Battery LED: (1) Green LED, indicates battery condition and charging status when docked
Memory
LPDDR2 RAM: 1 GB
Flash: 4 GB
Maximum Project Size: 512 MB
Graphics Engine
Supports Smart Graphics™ [11], multi-language Web browser[1,2], multi- language on-screen keyboard, screensaver
Languages
Smart Graphics: Arabic, Chinese (Simplified), Chinese (Traditional), Czech, Danish, Dutch, English (UK), English (US), Finnish, French, German, Greek, Hebrew, Hungarian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese, Portuguese (Brazilian), Romanian, Russian, Slovak, Spanish, Swedish, Thai
On-Screen Keyboard: Arabic, Chinese (Simplified), Croatian, Czech, Danish, Dutch, English (UK), English (US), Finnish, French (Canada), French (Switzerland), German, Hebrew, Hungarian, Italian, Japanese, Norwegian Bokmal, Polish, Portuguese, Russian, Serbian, Spanish, Swedish, Turkish Voice Recognition: Afrikaans (South Africa); Chinese, Mandarin (China, Simplified); Chinese, Mandarin (Hong Kong, Simplified); Chinese, Mandarin (Taiwan, Traditional); Chinese, Yue (Hong Kong, Traditional); Czech (Czech Republic); Dutch (Netherlands); English (Australia); English (Canada); English (Generic); English (India); English (New Zealand); English (South Africa); English (UK); English (US); French (France); German (Germany); isiZulu (South Africa); Italian (Italy); Japanese (Japan); Korean (South Korea); Polish (Poland); Portuguese (Brazil); Russian (Russia); Spanish (Spain); Turkish (Turkey)
Web Browser: Arabic, Bulgarian, Catalan, Chinese, Croatian, Czech, Danish, Dutch, English, Filipino, Finnish, French, German, Greek, Hebrew, Hindi, Hungarian, Indonesian, Italian, Japanese, Korean, Latvian, Lithuanian, Norwegian Bokmal, Pashto, Persian, Polish, Portuguese, Romanian, Romansh, Russian, Serbian, Slovak, Slovenian, Spanish, Swedish, Thai, Turkish, Ukrainian, Vietnamese
Wireless Communication (Primary) – Extended Range RF [8]
RF Transceiver: 2-way RF, 2.4 GHz ISM Channels 11-26 (2400 to
2483.5 MHz), IEEE 802.15.4 compliant
Transmitting Power: 75 mW (Ch.11), 100 mW (Ch.12-23), 15 mW (Ch.24), 3.5 mW (Ch.25), 1 mW (Ch.26) @ High Setting; 1 mW (Ch.11-25), 0.5 mW (Ch.26) @ Low Setting
Range (typical): 100 to 200 feet (30 to 60 m) maximum indoor, 1000 feet (300 m) outdoor, subject to site-specific conditions
Gateway: Requires a Crestron Extended Range (ER) Wireless Gateway[4]
Roaming: Supports roaming between a maximum of eight gateways
Wireless Communication (Secondary) – Wi-Fi® [8]
Transceiver: IEEE 802.11b/g/n Wi-Fi (2.4 GHz 2-way RF), static IP or dynamic IP via DHCP
Security: 64 & 128-bit WEP, WPA™ & WPA2™-PSK with TKIP & AES Range: Up to 50 feet (15 m), subject to site-specific conditions Gateway: Requires a CEN-WAP-1500 or similar 802.11b/g/n wireless access point and Ethernet-enabled Crestron control system
Handoff: Supports handoff between a maximum of four Wi-Fi wireless access points[7]
Wired Communications
Ethernet[1]: (Via table or wall dock) 10/100 Mbps, auto-switching, auto- negotiating, auto-discovery, full/half duplex, DHCP
USB: USB client for console only
Video
Streaming Formats: H.264 (MPEG-4 part 10 AVC) or MJPEG, up to 1024x720 @ 30 fps [1]
Audio
Features: Built-in microphone and speakers, Rava® SIP Intercom[1], multi- language voice recognition[1,2]
Audio Feedback Formats: MP3
Connectors
Docking Connector: (1) multi-pin connector;
Mates with the docking port on the table or wall dock [9]
USB: (1) Mini-B USB console port, for installer use only; Mini-B to A USB cable included
NOTE: See TST-600-IMCW interface module specification for additional connectors[9]
Battery
Rechargeable Battery: Li-ion, 3.7 Volt, 3200 mAh, model TST-600-BTP[12] Usage per Charge: 3.2 hours continuous, 90 hours under normal use (10% active duty cycle with standby/power down enabled)
Charging Time: 2.5 hours with touch screen in standby, 3.5 to 5 hours during use
Power Requirements
Power Pack: 0.75 Amps @ 24 Volts DC;
100-240 Volts AC, 50/60 Hz power pack, model PW-2407WU included
Cresnet® Power Usage: 18 Watts (0.75 Amps @ 24 Volts DC)[10]
Note: May be powered by power pack or Cresnet network power, not both. All power connections are made via the TST-600-IMCW interface module[9,10]
Environmental
Temperature: 32° to 112°F (0° to 45°C);
50° to 104°F (10° to 40°C) while charging
Humidity: 10% to 90% RH (non-condensing)
Heat Dissipation: 40 BTU/hour
Construction
Enclosure: Plastic, non-slip grips/feet, integral docking port
Front Bezels: Plastic, button and no-button bezels included, button
bezel includes white translucent illuminated Up/Down and Navigation Pad buttons and 8 hardkey buttons with illuminated dividers and default backlit text engraving, optional custom backlit text engraving sold separately[3]
Dimensions
Height: 5.10 in (130 mm)
Width: 8.08 in (206 mm)
Depth: 1.59 in (41 mm)
Note: Combined height of the TST-602 touch screen docked on the TST-600-DS table dock[9] is 3.30 in (84 mm)
Weight
22.5 oz (636 g) without table dock or interface module
